Information about trailer
Toilet trailers are practical solution used on events and festivals. Trailers are made of isothermal sandwich panels and high quality components. All models are equipped with flushing toilets, hot water and electric heating elements.
Basic equipment
Steel solid frame, hot-dip galvanised, V-drawbar
Jockey wheel
Plastic wheel wedges
Telescopic crank drop legs 4x
Plywood floor + PVC linoleum, standard colour grey
Steel sheet sandwich 50mm body in silver/gray-white colour
Water connection 3/4" + hoses L: 20 m
Electro connection + cable L: 20 m
Interior equipment according drawing
Bulb lighting 12V, 13-pin plug
For trailers with loading floor over 5m: Lighting 12-24V full LED, 13-pin plug
Basic trailer variants
| Name | Bedding area l × w × h (mm) | Braking | Total weight | |
|---|---|---|---|---|
WC 1073 |
1100 × 1200 × 2120 |
No |
750 kg |
|
WC 1074 |
1100 × 1200 × 2120 |
No |
750 kg |
|
WC E 15.26 111 |
2600 × 2170 × 2130 |
Yes |
1 500 kg |
|
WC E 27.50 313 |
5030 × 2170 × 2130 |
Yes |
2 700 kg |
|
WC E 27.56 314 |
5630 × 2170 × 2130 |
Yes |
2 700 kg |
|
WC F 27.65 414 |
6450 × 2400 × 2130 |
Yes |
2 700 kg |
